A visible plexus beneath gently winding loops

Mostly slender hairpin capillaries with mild limb curvature and a visible deeper vascular plexus.

Mostly slender hairpin capillaries with mild limb curvature and a visible deeper vascular plexus.
Mostly slender hairpin capillaries with mild limb curvature and a visible deeper vascular plexus.

Image details

Pattern
Tortuous capillaries
Author or contributor
Borja Gracia Tello
Hallmarks
Tortuous capillariesSimple hairpin loops
Magnification
250×
Device
Smart G-Scope
Field of view (W × H)
≈ 2.36 × 1.33 mm
Open full-size image

Teaching point

Subpapillary venous plexus: it may be seen in healthy individuals, so it does not define pathology by itself.

Measurements and calibration

For the subset of apices with stable automated measurements, estimated widths span approximately 12–21 µm. These are automated estimates, not manually validated measurements.

Clinical caveat

This image illustrates a visual finding and should be interpreted with acquisition quality, distribution across fingers, clinical context, and serology when relevant.

Use and licensing

Third-party image. Refer to the credits and any image-specific terms of use.

CC BY 4.0

Creator
Borja Gracia Tello

Image source page

Suggested attribution

A visible plexus beneath gently winding loops — Borja Gracia Tello, via Capillaroscopy.com.
CC BY 4.0.
Source: https://capillaroscopy.com/en/library/gracia-tello-hemorrhage-031/
Licence: https://creativecommons.org/licenses/by/4.0/

If you modify the image, describe your changes and retain any existing modification notices. This licence does not imply endorsement or clear other rights.
