An angular loop beneath a superficial crease
A capillary right of center has a sharp bend below its rounded apex. The surrounding hairpins are finer.
Image details
- Pattern
- Tortuous capillaries
- Author or contributor
- Borja Gracia Tello
- Hallmarks
- Tortuous capillariesCapillary dilation
- Magnification
- 250×
- Device
- Smart G-Scope
- Field of view (W × H)
- ≈ 2.33 × 1.31 mm
Teaching point
One isolated abnormal shape may be nonspecific.
Measurements and calibration
For the subset of apices with stable automated measurements, estimated widths span approximately 15–40 µm. These are automated estimates, not manually validated measurements.
Clinical caveat
This image illustrates a visual finding and should be interpreted with acquisition quality, distribution across fingers, clinical context, and serology when relevant.
