Slender loops with an irregular peripheral tip

Slender capillaries with occasional angulated limbs and unequal apical widths. An irregular loop is partly visible at the right edge.

Slender capillaries with occasional angulated limbs and unequal apical widths. An irregular loop is partly visible at the right edge.
Slender capillaries with occasional angulated limbs and unequal apical widths. An irregular loop is partly visible at the right edge.

Image details

Recorded diagnosis
  • Limited systemic sclerosis
Pattern
Tortuous capillaries
Author or contributor
Borja Gracia Tello
Hallmarks
Tortuous capillariesUnequal capillary calibers
Magnification
250×
Device
Smart G-Scope
Field of view (W × H)
≈ 2.33 × 1.31 mm
Open full-size image

Teaching point

If a loop cannot be classified safely, it is better to declare it doubtful or non-evaluable.

Measurements and calibration

For nonbranching apices with stable automated measurements, estimated widths span approximately 10–31 µm. These are automated estimates, not manually validated measurements.

Clinical caveat

This image illustrates a visual finding and should be interpreted with acquisition quality, distribution across fingers, clinical context, and serology when relevant.

Use and licensing

Third-party image. Refer to the credits and any image-specific terms of use.

CC BY 4.0

Creator
Borja Gracia Tello

Image source page

Suggested attribution

Slender loops with an irregular peripheral tip — Borja Gracia Tello, via Capillaroscopy.com.
CC BY 4.0.
Source: https://capillaroscopy.com/en/library/gracia-tello-tortuous-030/
Licence: https://creativecommons.org/licenses/by/4.0/

If you modify the image, describe your changes and retain any existing modification notices. This licence does not imply endorsement or clear other rights.
