ACA-positive systemic sclerosis: overview
Overview of the nailfold in the ACA-positive active-pattern case. The reported density and giant-capillary percentage describe the study, not this photograph alone.
Source study context
Capillaroscopy shows marked capillary loss (5.3/mm), frequent dilations, high prevalence of giant capillaries (27.5%), and hemorrhages, matching an active Cutolo pattern.
Measurements and classification refer to the described study or visit; they are not new measurements of this image.
View the complete case and studyImage details
- Pathology
- Limited Cutaneous Systemic Sclerosis (ACA+)
- Pattern
- Active scleroderma pattern
- Author or contributor
- Gema María Lledó Ibáñez
- Hallmarks
- Active scleroderma pattern
- Magnification
- 50×
- Device
- Dino-Lite
- Field of view (W × H)
- ≈ 7.23 × 5.78 mm
Teaching point
Review several fingers before concluding that density is low or the pattern is abnormal.
Clinical caveat
This image illustrates a visual finding and should be interpreted with acquisition quality, distribution across fingers, clinical context, and serology when relevant.
