Normal reference: distal capillary row

A field from the normal reference study, showing the distal row of narrow loops. Use the full study to compare density and shape across fingers.

A field from the normal reference study, showing the distal row of narrow loops. Use the full study to compare density and shape across fingers.
A field from the normal reference study, showing the distal row of narrow loops. Use the full study to compare density and shape across fingers.

Source study context

The complete image set shows a regular distal row, preserved density, absent giant capillaries, and no avascular areas.

Measurements and classification refer to the described study or visit; they are not new measurements of this image.

View the complete case and study

Image details

Pathology
Normal Capillaroscopy
Pattern
Normal Pattern
Author or contributor
Miguel Antonio Mesa Navas
Hallmarks
Capillary densityTortuous capillaries
Magnification
250×
Device
Smart G-Scope
Field of view (W × H)
≈ 2.35 × 1.32 mm
Open full-size image

Teaching point

Predominant morphology: hairpin, inverted "U", or mildly tortuous loops.

Clinical caveat

This image illustrates a visual finding and should be interpreted with acquisition quality, distribution across fingers, clinical context, and serology when relevant.

Use and licensing

Contributed by Miguel Antonio Mesa Navas for educational publication on Capillaroscopy.com. For reuse permissions, contact the rights holder.

Image source page

Image licensing and reuse

Related images

Back to atlas
Dark hemorrhagic deposits alongside capillary loops in the nonspecific reference study. Hemorrhage alone does not define a scleroderma pattern.Nonspecific pattern: hemorrhagic fieldIrregular, ramified loops in a field from the late-pattern reference study. The full study provides context for capillary loss and distribution.Late scleroderma pattern: disorganized loopsProminent enlarged loops and a complex branching form in the initial anti-NXP2 dermatomyositis study. Compare this with the linked follow-up image and complete serial studies.Anti-NXP2 dermatomyositis: initial enlarged loopsFollow-up field from the adult anti-NXP2 dermatomyositis case. The source report documents improved study-wide density and disappearance of giants and hemorrhages; these are longitudinal study findings.Anti-NXP2 dermatomyositis: follow-up field
